MSR145 Miniature Signal Data Recorder
|
|
>> Measures Temperature, Humidity, Light, Pressure and Acceleration Simultaneously and 2 or 4 Analog Inputs Also Available >> Stores up to 2 Million (Internal Memory) or 1 Billion (SD Card) Total Readings >> Rechargeable Lithium Polymer Battery >> Data from any number of loggers can be merged synchronously into a single Data Record >> Accelerometer Range of ±15g with -20°C to 65°C Temperature Range >> MSR PC Software Manages Settings and View, Edit, Export Data >> External Temperature, Humidity, Light, Air and Fluid Pressure Sensors Available >> Includes CD Software and USB Cable
Multiple Measurement Parameters Available >> Temperature >> Humidity >> Air Pressure (0 to 2000mbar or 0 to 14bar) >> Fluid Pressure (0 to 3000mbar or 0 to 30bar) >> Acceleration >> Light Level >> 2 or 4 Analog Inputs External Sensors Available for Temperature, Humidity, Pressure and LIght (Call 1-603-746-5524 to Order)
Included with each MSR145 >> Software CD >> USB Cable
NOTE: All External Sensors are Available as a Special Order. Large Quantity Discounts Are Available!
All MSR145s are Built... |
MSR Dataloggers
|
|
|
|
|
|
MSR255 LCD Data Loggers - with 5 Internal Sensor Options and 4 Analog Inputs
|
|
LCD Miniature Data Logger
MSR Electronics Universal Data Logger with 5 Internal Sensor Options and 4 Analog Inputs
>> Measures Temperature, Humidity, Light, Air Pressure and Acceleration Simultaneously and Includes 4 Analog Inputs >> LCD Display Shows up to 4 Current Values, Battery Status and Alarm Values >> Stores up to 2 Million Total Readings on Internal Memory >> Rechargeable Lithium Polymer Battery >> Data from any number of loggers can be merged synchronously into a single Data Record >> Accelerometer Range of ±15g with -20°C to 65°C Temperature Range >> MSR PC Software Manages Settings and View, Edit, Export Data >> External Temperature, Humidity, Light and Air Pressure Sensors Available >> Includes CD Software and USB Cable
Multiple Measurement Parameters Available >> Temperature >> Humidity >> Air Pressure (0 to 2000mbar or 0 to 14bar) >> Acceleration >> Light Level External Sensors Available for Temperature, Humidity and Pressure |
MSR Dataloggers
|
|
|
|
|
|
MSR160 Mini Datalogger w/ 4 Additional Analog Inputs
|
|
>> 4 Integrated Analogue Inputs Sample up to 1000 per Second >> Stores up to 2 Million Recorded Readings >> 0 to 3.0 Volt Measurement Range for Analog Inputs (Additional Ranges Available: 0 to 20mA, 4 to 20mA, 0.5V to 4.5V, 0 to 5V, 1V to 6V, 0 to 10V, 0 to 12V and 0 to 24V by Special Order) >> Each Analog Input Can Be Replaced with Internal or External Sensor >> Internal Sensors Available for Temp, Humidity, Pressure & 3-Axis Acceleration >> External Sensors Available for Temperature, Humidity & Air Pressure >> USB Interface for Transferring Data to Computer >> Waterproof Version Available >> Anodised Aluminum Case with Rechargeable Lithium Polymer Battery >> Optional Expansion Slot for MicroSD Card to Store 1 Billion Measurements Available >> Includes MSR PC Software to Manage Settings and View, Edit, Export Measured Data |
MSR Dataloggers
|
|
|
|
|
|
MSR165 Shock and Vibration Recorder
|
|
MSR165 Shock and Vibration Data Logger
MSR Electronics Data Recorder with Built-in 3-Axis Accelerometer with Rechargeable Lithium-Polymer Battery
MSR165
Please open the Configurator tab to choose your desired options.
Capable of Making 1600 Acceleration (Shock, Vibrations) Measurements per Second in All 3 Axes
32 Measurement Values are Recorded Even Before the Event Takes Place
Measurement Range of ±15g or ±200g in -20°C to 65°C Temperature Range
Rechargeable 900 mAh Lithium Battery or (2) LI-SOCI2 Replaceable Batteries Available
Also Records Temperature, Humidity, Air Pressure, Light and 4 Analog Input Signals
Made in Switzerland, Swiss Made
Includes USB Cable, Mounting Screws, and Quick Start Guide. ShockViewer Add-On Available as a Free Download
External Sensors (Temperature, Humidity, Pressure and Light) and 4 Analog Inputs Available.
MSR165: Data Logger for Shocks and Vibration
The MSR165 shock and vibration data logger is a robust mini data logger, capable of taking 1600 measurements per second for up to five years. It is ideal for measuring vibrations and monitoring shocks in the fields of transportation monitoring, fault... |
MSR Dataloggers
|
|
|
|
|
|
MSR12 Signal Data Recorder - MSR Electronics Portable and Expandable Data Logger Capable of Measuring Almost any Analog or Digital Signal
|
|
MSR Electronics Portable and Expandable Data Logger Capable of Measuring Almost any Analog or Digital Signal
The MSR12 Modular Signal Recorder is a practical, portable signal acquisition instrument for measuring, displaying and recording a range of environmental paramters. With its modular and expandable design, plug-in modules are available to record almost any signal. MSR PC Software Manages Settings and View, Edit, Export Measured Data.
The Basic MSR12 System includes >> (2) Modules: 3-Axis Accelerometer and PR8 Pressure Modules >> (3) Sensors: Acceleration, Air Pressure, Ambient Temperature >> PC Software >> Mains AC Adapter >> User Manual and Warranty |
MSR Dataloggers
|
|
|
|
|
|
MSR PC Software Version 5.12.04 with MSR Setup
|
|
MSR PC Software
Version 5.12.04 with MSR Setup, MSR Reeder, MSR Online and MSR Viewer Software Programs
MSR Software Consists of 4 Separate Programs >> MSR Setup: Used to Configure MSR Data Loggers >> MSR Reader: Download Data from Logger to PC >> MSR Online: View Data On-screen and Save Data to PC >> MSR Viewer: Data Viewed on PC in Graph or Table Format
MSR Software System Requirements >> Windows 7, Vista, XP, 2000 PC Operating System >> USB Port
Software is Included with the Purchase of an MSR Data Logger. |
MSR Dataloggers
|
|
|
|
|
|
MSR0002-MSR175 Transportation Data Logger - Records Shock and Temperature Malaysia
|
|
MSR175 Transportation Data Logger - Records Shock and Temperature
Built-in (2) 3-Axis Acceleration Sensors and (1) Temperature Sensor
Records in Range of ±15g/±200g and -20°C to 65°C Temperature Range
Stores Over 2,000,000 Measured Values, Which is Sufficient for more than 1,000 Shocks and Jolt Events
Rechargeable 260 mAh Lithium Polymer Battery
Data from any number of loggers can be merged synchronously into a single Data Record
Made in Switzerland, Swiss Made
Includes USB Cable, Mounting Screws, and Quick Start Guide. MSR Dashboard Software Available as a Free Download
MSR175 Shock Transportation Data Recorder with Plug-in Sensors Specifications
Measured Parameters
3-Axis Acceleration and Temperature
Acceleration
Number of Sensors: 2Measurement Range: ±15g and ±200gAccuracy (±15g): ±0.15g (25°C)Accuracy (±200g): ±2g@ 25°CMeasurement Rate (±15g): 6,400 Samples per Second
Temperature
Measurement Range: -20°C to 65°C;Accuracy: ±0.5°C (-10°C to 65°C)Measurement Rate: 10 Minutes
Data Storage Capacity
Over 2 Million Total Recorded Readings
Key
Start Measurement/Retrieve Status
Color
Amber
LEDs
Blue: Recording... |
MSR Dataloggers
|
|
|
|
|
|
MSR0001-MSR175 Transportation Data Logger - Records Shock, Temperature, Humidity, Pressure and Light Malaysia
|
|
MSR175 Transportation Data Logger - Records Shock, Temperature, Humidity, Pressure and Light
Internal Sensors for 3-Axis Acceleration, Air Pressure, Light, Humidity and Temperature
Records in Range of ±15g/±200g and -20°C to 65°C Temperature Range
Stores Over 2,000,000 Measured Values, Which is Sufficient for more than 1,000 Shocks and Jolt Events
Rechargeable 260 mAh Lithium Polymer Battery
Data from any number of loggers can be merged synchronously into a single Data Record
Made in Switzerland, Swiss Made
Includes USB Cable, Mounting Screws, and Quick Start Guide. MSR Dashboard Software Available as a Free Download
MSR175 Shock Air Pressure Light Humidity and Temperature Data Recorder Specifications
Measured Parameters
3-Axis AccelerationAir PressureLightHumidityTemperature
Acceleration
Number of Sensors: 2Measurement Range: ±15g and ±200gAccuracy (±15g): ±0.15g (25°C)Accuracy (±200g): ±2g @ 25°CMeasurement Rate (±15g): 6,400 Samples per Second
Air Pressure
Number of Sensors: 1Measurement Range: 0 to 2000mbar absoluteAccuracy: ±2.5mbar (25°C)Measurement Rate: 1 Sample per 10 Minutes
Light
Number of Sensors: 1Measurement... |
